Match UP 8BMW Plug & Play 8 Channel Amplifier & DSP for BMW E, F, G30 Hi-Fi 676

MATCH UP 8BMW

The Power Save Mode is incorporated in the basic setup. It allows to significantly reduce the power consumption of the UP 7BMW and potentially connected amplifiers once there’s no input signal present for more than 60 seconds.

MATCH UP 8BMW

„M-Power“ for your BMW HiFi sound system

The MATCH UP 8BMW is the "M Package" for your BMW HiFi sound system! This high performance 8-channel plug & play upgrade amplifier with integrated 9-channel 64 Bit DSP was specifically designed for BMW E & F as well as G30 / G31 (pre-facelift) with HiFi sound system (Option 676). It ensures a significantly more powerful and dynamic audio experience while offering seamless integration. Because a BMW deserves sound that matches its dynamics!

Features

• High-performance 8-channel Plug & Play upgrade amplifier with integrated 9-channel 64 Bit DSP for significantly more power and dynamics
• Specially developed for BMW E & F as well as G30 / G31 (pre-facelift) models with BMW HiFi sound system (Option 676)
• Easy and seamless installation at the original mounting location via included Plug & Play connection cable and mounting plate*
• Perfectly combinable with MATCH UPGRADE components – subwoofer, 2-way system & center speaker
• ACO – Advanced 32 Bit CoProcessor platform for extended feature set
• ISA (Input Signal Analyzer) and InputEQ for easy analysis and compensation of input signals
• Proprietary TuneEQ function for automated adjustment of the output equalizers
• SFX (DSP Sound Effects) – Augmented Bass Processing, RealCenter & Co.
• MEC slot for system expansions like Bluetooth® HD Audio Streaming, High Resolution Audio Streaming via USB etc.
• Start-Stop capability down to 6V supply voltage
• Mono RCA output for the connection of an external amplifier e.g. subwoofer amplifier MATCH UP 1FX
• Optical input in SPDIF format with sampling rate between 12 and 96 kHz
• SCP (Smart Control Port) for optional accessory like DIRECTOR, CONDUCTOR & Co.
• Easiest configuration via the intuitive DSP PC-Tool Software incl. VCP (Virtual Channel Processing) and TuneEQ

Seamless Integration and Convenient Upgrade Options

With the UP 8BMW, a simple and seamless integration into the BMW HiFi sound system at the original installation location is easily achievable thanks to the included plug & play connection cable and BMW-specific mounting plate. To facilitate further upgrades, it is perfectly designed for combination with other MATCH UPGRADE components for BMW vehicles, such as subwoofers, 2-way systems, and center speakers. With a total of eight amplifier channels and an additional preamp output, individual speaker configurations can be easily realized, thanks to the powerful 9-channel DSP. Two amplifier channels, each delivering 160 W output power at 2 Ohms, provide enough power to boost even large subwoofers. Furthermore, the MATCH UP 8BMW boasts enhanced connectivity, featuring an intelligent 6-channel highlevel input with the ADEP.3 circuit and a MEC slot for system expansions such as Bluetooth® HD audio streaming. It also includes a 1-channel mono line output for connecting external amplifiers like the MATCH UP 1FX and an optical input in SPDIF format with a sampling rate up to 96 kHz. Last but not least, it also comes with our SCP port for optional accessories like the DIRECTOR, CONDUCTOR etc.  

ACO – Advanced 32 Bit CoProcessor Plattform 

Of course, the UP 8BMW is equipped with our proprietary 32 Bit ACO platform, which doesn’t just take over all control tasks ultra-fast, but also handles a bunch of audio functions: fantastic sound effects such as Augmented Bass Processing or Real Center are implemented as well as a channel-separated Input EQ including Input Signal Analyzer (ISA) for easy analysis and compensation of input signals of OE radios, which already include a sound setup by default. 

DSP PC-Tool 5 feat. TuneEQ – Powerful features for the ultimate sound experience 

Of course, the MATCH UP 8BMW can be easily configured via our professional and exceptionally intuitive DSP PC-Tool 5. The familiar, numerous setting options leave nothing to be desired and guarantee an extremely precise sound adjustment even for complex system configurations. And thanks to the proprietary TuneEQ function for automated frequency response correction, you also save a lot of time when optimizing your sound.

Class GD technology

Audiotec Fischer´s proprietary Class GD concept takes the efficiency of conventional Class D amps to the next level. By varying the internal supply voltage in several steps depending on the amplifier’s input signals, idle losses are significantly reduced and overall efficiency is close to maximum at any time. So heat dissipation is almost negligible, thus allowing smallest heat sinks and most compact form factors.
