Edge Xtreme Series EDXPRO65T-E3 Single Pro Audio Tweeter 6.5 Inch 80w RMS
Couldn't Load Pickup availability
The Edge EDXPRO65T-E3 is a single pro audio compression driver from the Xtreme Series, fitted with a 6.5 inch flared titanium-diaphragm horn and rated at 80W RMS / 240W peak with 105dB sensitivity.
Key specifications
- Type: compression driver, 1-way, sold as a single
- Horn size: 6.5 inch (165mm)
- Power handling: 80W RMS, 240W peak
- Sensitivity: 105dB
- Frequency response: 1.2kHz to 20kHz
- Impedance: 6.6 ohms
- Diaphragm: titanium, ferro-fluid cooled voice coil
- Mounting depth: 3.7 inch (95mm)
- Mounting diameter: 5.3 inch (135mm)
EDXPRO65T-E3 compression driver
This high-frequency driver differs from a traditional tweeter. A high-power motor drives the large titanium diaphragm and voice coils with precision, paired with a 6.5 inch flared horn that allows the driver to play significantly lower than a conventional tweeter — down to 1.2kHz — so more of the directional sound originates from a single point.
The flared horn also delivers more progressive dispersion, increasing clarity, efficiency and output. The result is concert-level volume and detail suited to serious pro audio car builds.
Pairs with Edge Xtreme pro midrange drivers such as the EDXPRO6-E3 6.5 inch and EDXPRO8-E3 8 inch.
Features
- Pro audio compression driver
- Titanium diaphragm
- Flared horn design
- Ferro-fluid voice coil cooling
- Screw terminal
Explore the full range in Edge Xtreme Series.
Specification
| Frequency Response | 1.2kHz - 20kHz |
|---|---|
| Sensitivity | 105dB |
| Impedance | 6.6 Ohms |
| Mounting Depth | 3.7” (95mm) |
More specs
| |
What's Included
- EDXPRO65T-E3
Edge
About the Edge EDXPRO65T-E3
From our tech experts at CEN
The Edge EDXPRO65T-E3 is a single compression driver from the Xtreme Series, fitted with a 6.5 inch (165mm) flared horn and titanium diaphragm. It is rated at 80w RMS and 240w peak, with 105 dB sensitivity, 6.6 ohm impedance and a 1.2 kHz to 20 kHz range.
Who it suits
Pro audio and SPL builds with room for a large horn, where projection matters more than compact size. The wide horn controls dispersion and carries treble further. If space is tight, the EDXPRO35TN-E4 is the more compact Xtreme driver.
Our tech experts advise
Order two for a stereo pair. It needs a 135mm mounting hole and 95mm of depth, so plan the panel or pod first. High-pass it on the amplifier or with a suitable filter well above its 1.2 kHz lower limit. The voice coil is ferro-fluid cooled for sustained power. Installation is priced per vehicle, so get in touch.
Explore the full Edge range at CEN, with fast UK dispatch and expert advice from our Nottingham team. Shop all Edge
Recommended For You
Discover more top-rated gear, handpicked to go with what you're viewing
Have it Fitted By Our Team
Our team fits car audio, stereos, dash cams and vehicle security at our workshop in Beeston, Nottingham. Tell us your vehicle and we'll confirm the parts and a fitted price.
- 1
Tell us your vehicle
Make, model and year, and what you'd like fitted.
- 2
We confirm the parts
Fascia, wiring and interfaces checked for your car, with a fitted price.
- 3
Fitted at our workshop
Bring it to our Beeston workshop and we do the rest.
Unit 25 Technology Drive, Beeston, Nottingham NG9 1LA
More from Edge
More options from the same range, in stock and ready to go
Staff PickEdge SPL Sub 12 Inch Subwoofer Dual 2 Ohm Voice Coil 1500w RMS EDP122SPL-E3
£179.00
View product
Best SellerEdge DBX Series EDBX6-E1 3 Way Coaxial Speakers 6.5 Inch 90w RMS Pair
£39.99
Edge DBX Series EDBX150.4-E1 Amp Class AB 4 Channel Amplifier 600w RMS
£174.99
Edge DBX Series EDBXPB62.1-E5 6.5 Inch Full Range Ported Enclosure 1000w RMS
£249.99
Edge DBX Series EDBXPRO6-E2 Pro Audio Midrange Speakers 6.5 Inch 175w RMS Pair
£49.99
Frequently Asked Questions
Q: Is the EDXPRO65T-E3 sold as a single or a pair?
A: It is sold as a single compression driver. Order two for a left and right pair.
Q: What diaphragm does the EDXPRO65T-E3 use?
A: It uses a large titanium diaphragm driven by a high power motor, with ferro-fluid voice coil cooling and a 6.5 inch flared horn.
Q: How much power can the EDXPRO65T-E3 handle?
A: It is rated at 80W RMS and 240W peak, with 105dB sensitivity and a 6.6 ohm impedance.
Q: Can CEN fit this tweeter for me?
A: Yes. CEN offers professional installation from our Nottingham premises. Contact us to book an installation slot or ask for a fitting quote.
