Edge Xtreme Series EDX10D2-E3 Car Sub Dual 2 Ohms 10 Inch Subwoofer 1750w RMS
Couldn't Load Pickup availability
The Edge Xtreme Series EDX10D2-E3 is a 10 inch car subwoofer rated at 1750W RMS and 3500W peak, with dual 2 ohm voice coils and a triple stacked Y35 ferrite motor. It is part of Edge's Xtreme Series range, built for street and competition bass in enclosures from 1 to 2 cubic feet.
This listing is the 10 inch. The Xtreme Series subwoofer is also available in a 12 inch (EDX12D2-E3) and a 15 inch (EDX15D2-E3).
Key specifications
- Size: 10 inch, 234mm overall diameter
- Power handling: 1750W RMS, 3500W peak
- Impedance: dual 2 ohms
- Voice coil: 3 inch (76mm) black aluminium former, 4 layer
- Magnet: triple stacked Y35 ferrite, 190mm x 95mm x 20mm
- Enclosure volume: 1 to 2 cu ft
- Mounting depth: 170mm
Edge Xtreme Series subwoofer (EDX10D2-E3)
The Xtreme Series was designed with both street bass and competition bass in mind. All models use massive triple stacked motor structures across three basket types, each cast from aluminium for strength and rigidity. They pair polycotton spiders, stitched tinsel leads, non-pressed paper cones and 3 inch voice coils across a range of power ratings and sizes.
New for 2023: a custom tooled basket for increased excursion on low bass, a wider foam surround to handle that excursion, and a custom tooled 2-piece dust cap.
Features
- Non-pressed paper cone
- Wide roll dual foam surround
- High quality Y35 triple stacked ferrite magnets
- 76mm USA-built 4 layer flat wound voice coil
Explore the full range in Edge Xtreme Series.
Specification
| Cone | Non pressed paper cone |
|---|---|
| Surround | Big roll foam - dual stitched |
| Voice Coil | Former 3" Black Aluminium |
| Spider | 2pcs Black PC |
| Gasket | Rubber |
| Top Plate | 8mm Black anodized |
| T-Yoke | 10mm Black anodized flat |
| Terminal / Wire | Spring loaded connectors |
| Impedance | Dual 2 Ohms |
| RMS Power | 1750 watts |
| Peak Power | 3500 watts |
| Enclosure Volume | 1-2cuft |
| Magnet | 190mm x 95mm x 20mm 3pcs |
| Overall Diameter | 234mm |
| Mounting Depth | 170mm |
What's Included
- EDX10D2-E3
Edge
About the Edge EDX10D2-E3
From our tech experts at CEN
An Edge 10 inch subwoofer, dual voice coil, 2 ohm, handling 1750w RMS.
Who it suits
Drivers building a system where the bass does real work, and SPL builds where output is the point.
Our tech experts advise
Enclosure volume and tuning decide most of what you hear, and the dual coils give you wiring options. Bigger output builds also need the electrical side checked, because large amplifiers pull current the standard charging system was never designed for. Installation is priced per vehicle, so get in touch with your make, model and year and we will confirm what it needs. See car audio installation.
Explore the full Edge range at CEN, with fast UK dispatch and expert advice from our Nottingham team. Shop all Edge
Recommended For You
Discover more top-rated gear, handpicked to go with what you're viewing
Have it Fitted By Our Team
Our team fits car audio, stereos, dash cams and vehicle security at our workshop in Beeston, Nottingham. Tell us your vehicle and we'll confirm the parts and a fitted price.
- 1
Tell us your vehicle
Make, model and year, and what you'd like fitted.
- 2
We confirm the parts
Fascia, wiring and interfaces checked for your car, with a fitted price.
- 3
Fitted at our workshop
Bring it to our Beeston workshop and we do the rest.
Unit 25 Technology Drive, Beeston, Nottingham NG9 1LA
More from Edge
More options from the same range, in stock and ready to go
Staff PickEdge SPL Sub 12 Inch Subwoofer Dual 2 Ohm Voice Coil 1500w RMS EDP122SPL-E3
£179.00
View product
Best SellerEdge DBX Series EDBX6-E1 3 Way Coaxial Speakers 6.5 Inch 90w RMS Pair
£39.99
Edge DB Series EDB1000.1D-E4 Amp Class D 1 Channel Monoblock Amplifier 1000w RMS
£149.99
Edge DBX Series EDBXPB62.1-E5 6.5 Inch Full Range Ported Enclosure 1000w RMS
£249.99
Edge DBX Series EDBXPRO6-E2 Pro Audio Midrange Speakers 6.5 Inch 175w RMS Pair
£49.99
Frequently Asked Questions
Q: Do I need an amplifier for this subwoofer?
A: Yes, unless it is an active (powered) subwoofer with a built-in amplifier. Passive subwoofers need an external amplifier matched to the RMS power and impedance shown in the Specification tab.
Q: What size enclosure does this subwoofer need?
A: The recommended enclosure volume is listed in the Specification tab where the manufacturer provides it. As a rule, sealed enclosures give tighter, more accurate bass while ported enclosures deliver more output. Contact CEN if you would like a recommendation for your build.
Q: What does RMS power mean?
A: RMS is the continuous power a subwoofer can handle, and it is the number that matters when matching an amplifier. Peak or max figures describe short bursts only. Match your amplifier output to the RMS rating in the Specification tab.
Q: Sealed or ported enclosure - which should I choose?
A: Sealed boxes are compact and produce tight, controlled bass suited to sound quality builds. Ported boxes are larger and produce more output at low frequencies, suited to those who want maximum impact. Either works well when built to the recommended volume.
Q: Can CEN build or supply an enclosure and fit everything?
A: Yes. CEN supplies enclosures and offers professional installation from our Nottingham premises, including amplifier wiring. Contact us to discuss your build.
Q: What box does the EDX10D2-E3 need?
A: EDGE specifies an enclosure volume of 1 to 2 cubic feet.
Q: What impedance is the EDX10D2-E3?
A: It has dual 2 ohm voice coils, so it can be wired to 1 ohm or 4 ohms to suit your amplifier.
Q: How deep is the EDX10D2-E3?
A: The mounting depth is 170mm and the overall diameter is 234mm.
