The AudioControl PNW-35 is a pair of 3.5 inch 2-way coaxial speakers rated at 25W RMS, with a rear-dampened hybrid silk dome tweeter, rigid poly mica-coated cone and edge-enhanced steel frame. Part of AudioControl's PNW Series, they are a direct drop-in upgrade for factory 3.5 inch speaker locations.
Key specifications
- Size: 3.5 inch 2-way coaxial
- Power: 25W RMS / 50W max
- Frequency response: 90Hz–20kHz
- Crossover: Butterworth high-pass at 5900Hz, -6dB/octave
- Cut-out: 76.5mm
- Mounting depth: 39.5mm
- Voice coils: 13mm tweeter, 25mm midrange
- Overall diameter (with metal bracket): 113mm
- Supplied as: 2 x PNW-35 speakers
PNW Series 3.5" High-Fidelity Coaxial Speakers
AudioControl has over 45 years of experience engineering audio components. The PNW Series is designed to pair with AudioControl's amplifier range and deliver high-fidelity sound from standard factory speaker positions. The PNW-35 features an edge-enhanced steel frame for structural rigidity, a black anodized voice coil former for heat dissipation, and a linear double-roll surround for precise cone movement. The rigid poly mica-coated cone optimises sound reproduction across the frequency range.
Each set includes high-quality mounting hardware for a straightforward installation. The tweeter's point source design aligns the output of both drivers for improved speaker alignment and sound staging. For a more complete system, the PNW Series can be paired with AudioControl Spike or Space Series subwoofers. To connect PNW speakers to a factory head unit without RCA outputs, the AudioControl LC2i 2 Channel Line Out Converter is a compatible signal converter option.
Features
- Edge-enhanced steel frame for added structural strength
- Black anodized voice coil former for superior heat dissipation
- Linear double-roll surround for precision cone movement
- Complex FEA-designed high-efficiency motor
- Rigid poly mica-coated cone for optimised sound reproduction
- Rear-dampened hybrid silk dome tweeter for extended frequency response
- Concentric point source design for a seamless transition from midrange to tweeter
- Sonic diffuser and radiant collar for better off-axis frequency response
- High-quality mounting hardware included
Explore the full range in AudioControl.
Specification
| Crossover Type | Butterworth |
|---|---|
| Power | 25W RMS / 50W Max |
| DC Resistance (Re) | 1.75 ohms |
| Filter Type | HP |
| Frequency Response | 90-20k Hz |
| XO Frequency | 5900 Hz |
| Slope (Octave) | -6 dB |
| Tweeter Voice Coil Diameter | 13 mm |
| Midrange Voice Coil Diameter | 25 mm |
| Overall Diameter (w/ metal bracket) | 4.44 in/ 113 mm |
| Cut Out Diameter | 3.0 in/ 76.5 mm |
| Mounting Depth | 1.55 in/ 39.5 mm |
| Motor Diameter (w/ Cover) | 2.96 in / 75.4 mm |
What's Included
- 2 x PNW-35 Speakers
- Manual
- Warranty
AudioControl
About the AudioControl PNW-35
From our tech experts at CEN
AudioControl 3.5 inch coaxial speakers, rated at 25w RMS.
Who it suits
Drivers replacing tired factory speakers who want a clear improvement without complication.
Our tech experts advise
Sizes, adapter rings and harnesses vary by vehicle, year and trim, so we confirm what your car takes before ordering rather than guessing. Door treatment matters as much as the speaker. Installation is priced per vehicle, so get in touch with your make, model and year and we will confirm what it needs. See car audio installation.
Explore the full AudioControl range at CEN, with fast UK dispatch and expert advice from our Nottingham team. Shop all AudioControl
Recommended For You
Discover more top-rated gear, handpicked to go with what you're viewing
Looking for Installation?
At CEN we take pride in being able to share the quality of our work as well as being able to show what incredible products we have installed week on week.
More from AudioControl
More options from the same range, in stock and ready to go
Frequently Asked Questions
Q: Will these speakers fit my car?
A: Most car speakers are standard sizes, but mounting depth and fitting rings vary by vehicle. Check the size in the Specification tab against your vehicle, or contact CEN with your registration and we will confirm fitment and any adapters or fitting kits you need.
Q: Do I need an amplifier to run these speakers?
A: Not always. Most speakers will run from a standard head unit, but a dedicated amplifier lets them perform at their best, particularly for component sets and higher power handling models. The RMS figure in the Specification tab is the guide to how much clean power they can use.
Q: What is the difference between coaxial and component speakers?
A: Coaxial speakers combine the tweeter and woofer in one unit for a simple like-for-like upgrade. Component sets separate the tweeter and woofer with a crossover for better imaging and detail, and suit installs where sound quality is the priority.
Q: Do these come as a pair?
A: Unless stated otherwise, car speakers are sold in pairs. Check the product title and What's Included tab, which lists exactly what is in the box.
Q: Can CEN fit these speakers for me?
A: Yes. CEN offers professional installation from our Nottingham premises. Contact us to book an installation slot or ask for a fitting quote.
Q: What size hole does the PNW-35 need?
A: The cut-out is 76.5mm and the mounting depth is 39.5mm. Check these against your vehicle, or contact CEN for a fitment check.
Q: How much power can the PNW-35 handle?
A: They are rated at 25W RMS and 50W max per speaker, with a frequency response of 90Hz-20kHz.
Q: Does the PNW-35 have a built-in tweeter?
A: Yes. It is a 2-way coaxial with a rear-dampened hybrid silk dome tweeter mounted concentrically, fed through a Butterworth high-pass crossover at 5900Hz.
