Morel Elate Carbon MW6 6.5 Inch Component Woofers 180w RMS

The Morel Elate Carbon MW6 is a pair of 6.5 inch component woofers from Morel's Elate Carbon range, rated at 180W RMS. They feature a 75mm (3") Hexatech aluminium voice coil on a titanium former, a three-layer carbon fibre and Rohacell cone, and Morel's EVC motor technology.

The MW6 is the 6.5 inch woofer used in the Elate Carbon 62 and Elate Carbon 63 component systems.

Key specifications

• Size: 165mm (6.5") unit diameter
• Mounting: 141mm cutout, 61mm depth
• Impedance: 4 ohms
• Power handling: 180W RMS, 1000W max transient
• Sensitivity: 87 dB (2.83V/1m)
• Frequency response: 30 – 4000 Hz
• Resonant frequency: 45 Hz
• Voice coil: 75mm (3") Hexatech aluminium, titanium former
• Xmax: +/- 4.75mm
• Cone: one-piece formed, 3-layer carbon fibre and Rohacell sandwich

Morel Elate Carbon MW6 Woofers

The Elate Carbon woofers take their name from their triple-layer cones: two layers of carbon fibre sandwiching a Rohacell foam core. This construction delivers exceptional stiffness, high damping and low mass — the three key factors in cone performance.

Combined with a 75mm Hexatech aluminium voice coil, titanium former, and Morel's EVC motor technology, the MW6 achieves tight control and low distortion for transparent, bass-rich sound reproduction in high-end component systems.

Features

Carbon Fibre Cone

Derived from Morel's award-winning fat lady speaker system, the cone uses two carbon fibre skins sandwiching a layer of Rohacell — a high-strength, lightweight foam. The result is a cone that is light, stiff and well-damped for naturally uncoloured audio reproduction.

EVC Motor

Morel's EVC™ technology uses a large voice coil for improved heat dissipation, power handling and linearity. The motor system sits within the voice coil, eliminating stray magnetic flux by directing all magnetic energy to the coil. The EVC architecture is efficient, magnetically shielded and highly compact.

Hexatech Aluminium Voice Coil

The Hexatech™ voice coil is wound from 100% aluminium wire in a honeycomb shape, reducing air gaps in the windings and increasing efficiency by up to 20%. Its low mass contributes to the fast transient response Morel drive units are known for.
