Edge DBX Series EDBXPRO6W-E0 Pro Audio Midrange Speakers 6 Inch 150w RMS Pair
Couldn't Load Pickup availability
The Edge EDBXPRO6W-E0 is a pair of 6 inch (150mm) pro audio midrange speakers from the Edge DBX Series, rated at 150W RMS (300W peak) each, with a full-range 100Hz–20kHz response.
This listing is the 6 inch model. The Edge DBX Pro Audio Midrange range is also available in 8 inch (175W RMS).
This is the 6 inch wideband DBX Pro model. Its shallow 61mm mounting depth suits doors and pods where space is tight. Edge recommends the EDA350.2-E7 amplifier to drive it. The full-range design means it can be used with or without a tweeter.
Key specifications
- Model: EDBXPRO6W-E0
- Type: 1 way pro audio midrange (full range)
- Size: 6" (150mm)
- Power: 150W RMS / 300W peak
- Sensitivity: 90dB
- Frequency response: 100Hz–20kHz
- Impedance: 4 ohms
- Mounting depth: 61mm, mounting diameter: 140mm
- Sold as: pair
Edge DBX Series Pro Audio Midrange Speakers
The DBX Series Pro range includes 6.5 inch, 8 inch and 6x9 inch models designed for high-volume sound reproduction.
Built on the foundations of the Edge DB Series, the DBX Series advances performance through larger magnets, redeveloped voice coils, and precision-designed spiders and cones for louder, more efficient sound.
The 6 inch model uses a wideband full-range design, reproducing the full frequency range without needing a separate tweeter. Paired with DBX Series tweeters, the speakers deliver a significant step up in volume, efficiency and sound quality.
Features
- Non pressed paper cone
- Dual roll foam surround
- Polycotton spiders
- Spade terminals
- EVA gasket
Explore the full range in Edge DBX Series.
Specification
| Type | Pro Audio Midrange |
|---|---|
| Configuration | 1 way |
| Speaker Size | 6" (150mm) |
| RMS Power | 150 watts |
| Peak Power | 300 watts |
| Sensitivity | 90dB |
| Frequency Response | 100Hz - 20kHz |
| Impedance | 4 Ohms |
| Recommended Amplifier | EDA350.2-E7 |
| Mounting Depth | 2.4" (61mm) |
| Mounting Diameter | 5.5" (140mm) |
What's Included
- EDBXPRO6W-E0
Edge
About the Edge EDBXPRO6W-E0
From our tech experts at CEN
Edge pro audio midrange drivers, 6 inch, handling 150w RMS, built for efficiency and output rather than background listening.
Who it suits
Loud builds and show cars, where efficiency is what makes a system go loud without enormous amplifier power.
Our tech experts advise
Pro drivers usually need baffle or pod mounting and a crossover set well clear of their limits; they are not a straight door swap. Installation is priced per vehicle, so get in touch with your make, model and year and we will confirm what it needs. See car audio installation.
Explore the full Edge range at CEN, with fast UK dispatch and expert advice from our Nottingham team. Shop all Edge
Recommended For You
Discover more top-rated gear, handpicked to go with what you're viewing
Have it Fitted By Our Team
Our team fits car audio, stereos, dash cams and vehicle security at our workshop in Beeston, Nottingham. Tell us your vehicle and we'll confirm the parts and a fitted price.
- 1
Tell us your vehicle
Make, model and year, and what you'd like fitted.
- 2
We confirm the parts
Fascia, wiring and interfaces checked for your car, with a fitted price.
- 3
Fitted at our workshop
Bring it to our Beeston workshop and we do the rest.
Unit 25 Technology Drive, Beeston, Nottingham NG9 1LA
More from Edge DBX Series
More options from the same range, in stock and ready to go
Edge DBX Series EDBXPRO8-E4 Pro Audio Midrange Speakers 8 Inch 200w RMS Pair
£79.99
View product
Edge EDBX10A-E0 DBX Series Shallow Active Bass Enclosure 180w RMS
RRP £159.99Save 6%£149.00
Edge DBX Series EDBX2200.1D-E4 Amp Class D 1 Channel Mono Amplifier 2200w RMS
RRP £249.99Save 4%£239.99
Edge DBX Series EDBX1800.1D-E4 Amp Class D 1 Channel Mono Amplifier 1800w RMS
£199.99
Edge DBX Series EDBX150.4-E1 Amp Class AB 4 Channel Amplifier 600w RMS
£174.99
Frequently Asked Questions
Q: Will these speakers fit my car?
A: Most car speakers are standard sizes, but mounting depth and fitting rings vary by vehicle. Check the size in the Specification tab against your vehicle, or contact CEN with your registration and we will confirm fitment and any adapters or fitting kits you need.
Q: Do I need an amplifier to run these speakers?
A: Not always. Most speakers will run from a standard head unit, but a dedicated amplifier lets them perform at their best, particularly for component sets and higher power handling models. The RMS figure in the Specification tab is the guide to how much clean power they can use.
Q: Do these come as a pair?
A: Unless stated otherwise, car speakers are sold in pairs. Check the product title and What's Included tab, which lists exactly what is in the box.
Q: Can CEN fit these speakers for me?
A: Yes. CEN offers professional installation from our Nottingham premises. Contact us to book an installation slot or ask for a fitting quote.
Q: Can the EDBXPRO6W-E0 be used without a tweeter?
A: Yes. The 6 inch DBX model has a full range design with a 100Hz to 20kHz response, so it can be used without a tweeter. Adding DBX Series tweeters gives extra high frequency output.
Q: What amplifier does Edge recommend for the EDBXPRO6W-E0?
A: Edge recommends the EDA350.2-E7 amplifier. Each speaker is rated at 150W RMS (300W peak) at 4 ohms.
Q: What is the mounting depth of the EDBXPRO6W-E0?
A: The mounting depth is 2.4 inches (61mm) and the mounting diameter is 5.5 inches (140mm).
