The AudioControl EPICFOUR is a compact, 2-ohm stable Class D 4-channel car amplifier delivering 4 x 200 W RMS at 2 ohms (800 W total RMS). It belongs to the AudioControl EPIC Series.
Key specifications
- Channels: 4 (bridgeable), Class D, 2-ohm stable
- Power (RMS at 14.4 V): 4 x 100 W at 4 ohms, 4 x 200 W at 2 ohms, 2 x 400 W bridged at 4 ohms
- High pass filter: 12 dB/octave Linkwitz-Riley, off, 50 Hz to 500 Hz
- Line-level inputs: 500 mV to 12 V RMS
- Frequency response: 10 Hz to 22 kHz (+/- 1 dB)
- S/N ratio: 90.1 dBA (ref 100 W at 4 ohms)
- Power/ground wire: 4 AWG, speaker terminals: 8 AWG, recommended fuse: 80 A
- Dimensions: 6.1" W x 9.41" L x 2.01" H
AudioControl EPIC Series 4-Channel 800 W Amplifier
The EPICFOUR is part of the AudioControl EPIC Series, built around a high-current Class D design in a compact, thermally efficient chassis. It is 2-ohm stable for maximum power output, features a smart auto-reset protection circuit, and uses direct wire terminals secured by hex screws for solid, reliable connections.
Features
- Digital Class D amplifier: compact and powerful, 2-ohm stable for high output
- 12 dB/octave variable high pass filter (Linkwitz-Riley): adjustable from 50 Hz to 500 Hz to match your speakers
- Direct wire terminals with hex screws for secure connections
- 4-gauge power terminal and 8-gauge speaker terminal for maximum current flow
- 91 dB+ signal-to-noise ratio (CEA standard)
- Ultra-low idle current draw: less than 0.5 to 1 A
- Smart auto-reset protection circuit with multiple protection modes
Explore the full range in AudioControl Amplifiers.
Specification
| Line-Level Inputs | 500mV – 12V RMS |
|---|---|
| Dimensions | 6.1″ W x 9.41″ L x 2.01″ H |
| Frequency Response | (+/- 1 dB) 10 Hz – 22 kHz |
| S/N Ratio | 90.1 dBa, Ref 100 Watts @ 4 ohms |
| Power / Ground Wire Gauge | 4 AWG |
| Recommended Fuse Rating | 80 Amps |
| High Pass Filter | 12dB/octave Linkwitz-Riley, Off, 50 Hz to 500 Hz |
| Speaker Terminal Wire Gauge | 8 AWG |
More specs
| |
What's Included
- EPICFOUR
- Wrench
- Screws
- Manual
- Warranty
AudioControl
About the AudioControl EPICFOUR
From our tech experts at CEN
The AudioControl EPICFOUR is a Class D 4-channel car amplifier from the EPIC Series, delivering 800W RMS total — 4 x 200W at 2 ohms or 4 x 100W at 4 ohms. All four channels are bridgeable, giving 2 x 400W at 4 ohms. Its compact, thermally efficient chassis suits installs where space is limited.
Who it suits
The EPICFOUR is a good choice for anyone powering a full four-channel speaker system, including door and rear speakers, with solid output. The 2-ohm stability allows lower-impedance speaker loads without sacrificing power. For greater output across four channels, the AudioControl EPICBIGFOUR delivers 1400W RMS.
Our tech experts advise
Use 4 AWG cable for the power and ground runs and an 80A fuse at the battery; speaker terminals take 8 AWG. The variable Linkwitz-Riley high pass filter (50Hz to 500Hz, 12dB/octave) lets you protect tweeters and midrange drivers without a separate crossover. Line-level inputs accept 500mV to 12V RMS, which suits most head units. Fitting is priced per vehicle — ask us about car audio installation in Nottingham.
Explore the full AudioControl range at CEN, with fast UK dispatch and expert advice from our Nottingham team. Shop all AudioControl
Recommended For You
Discover more top-rated gear, handpicked to go with what you're viewing
Have it Fitted By Our Team
Our team fits car audio, stereos, dash cams and vehicle security at our workshop in Beeston, Nottingham. Tell us your vehicle and we'll confirm the parts and a fitted price.
- 1
Tell us your vehicle
Make, model and year, and what you'd like fitted.
- 2
We confirm the parts
Fascia, wiring and interfaces checked for your car, with a fitted price.
- 3
Fitted at our workshop
Bring it to our Beeston workshop and we do the rest.
Unit 25 Technology Drive, Beeston, Nottingham NG9 1LA
More from AudioControl
More options from the same range, in stock and ready to go
Frequently Asked Questions
Q: How much power does the EPICFOUR produce?
A: It delivers 4 x 100 W RMS at 4 ohms, 4 x 200 W RMS at 2 ohms (800 W total), or 2 x 400 W RMS bridged at 4 ohms, all at 14.4V.
Q: Does the EPICFOUR have a low pass filter for a subwoofer?
A: The EPICFOUR has a 12 dB/octave variable high pass filter (50 Hz to 500 Hz) for speakers. No low pass filter is listed, so it is designed mainly for driving speakers.
Q: What fuse and cable does the EPICFOUR need?
A: AudioControl recommends an 80 A fuse with 4 AWG power and ground wire, and 8 AWG speaker wire at the terminals.
