AudioControl EPIC750 Mono 1-Channel Amplifier 750w RMS
Couldn't Load Pickup availability
The AudioControl EPIC750 is a Class D monoblock subwoofer amplifier delivering 750 W RMS at 1 ohm. It features EPICBoost variable bass boost, an included ACR-E remote bass knob and an Epicenter Link connection for The Epicenter bass restoration processor. It is part of AudioControl's EPIC Series.
Key specifications
- Channels: 1 (monoblock), 1 ohm stable, strappable
- Power (RMS at 14.4V): 300 W at 4 ohms, 500 W at 2 ohms, 750 W at 1 ohm, 1500 W at 2 ohms strapped
- Low pass filter: 12 dB/octave Linkwitz-Riley, 40 Hz to 180 Hz
- Subsonic filter: 12 dB/octave Linkwitz-Riley, off to 50 Hz
- EPIC Boost: 30 Hz to 80 Hz centre, 0 to 12 dB gain
- Frequency response: 10 Hz to 190 Hz (+/- 1 dB)
- Line-level inputs: 500mV to 12V RMS
- S/N ratio: 92.2 dBA (ref 300 W at 4 ohms)
- Power/ground wire: 4 AWG, recommended fuse 80 A
- Dimensions: 6.1" W x 8.62" L x 2.01" H
AudioControl EPIC Series Monoblock 750 Watt Amplifier
The EPIC750 delivers high-power bass in a compact, thermally efficient Class D design. It pairs directly with The Epicenter bass restoration processor (sold separately) via the dedicated Epicenter Link, which carries power, ground and remote turn-on in a single tidy connection. The ACR-E remote bass knob is included for in-cabin level control. If your source unit lacks RCA outputs, AudioControl's LC2i 2-channel line out converter or LC6i 6-channel line out converter can provide a compatible signal feed.
Features
- Compact high-power Class D monoblock amplifier
- High-current design, 1 ohm stable
- Smart auto-reset protection circuit
- 12 dB/octave Linkwitz-Riley variable low pass filter
- 12 dB/octave variable subsonic filter
- EPICBoost variable frequency bass boost
- ACR-E remote level control (bass knob) included
- Solid power/speaker terminals with hex screws
- Built for The Epicenter
Explore the full range in AudioControl.
Specification
| Line-Level Inputs | 500mV – 12V RMS |
|---|---|
| Dimensions | 6.1″ W x 8.62″ L x 2.01″ H |
| Frequency Response | (+/- 1 dB) 10 Hz – 190 Hz |
| S/N Ratio | 92.2 dBa, Ref 300 Watts @ 4 ohms |
| Power / Ground Wire Gauge | 4 AWG |
| Recommended Fuse Rating | 80 Amps |
| Low Pass Filter | 12dB/octave Linkwitz-Riley, 40 Hz to 180 Hz |
| Subsonic Filter | 12 dB/octave Linkwitz-Riley, Off to 50 Hz |
| EPIC Boost | Frequency Center: 30 Hz to 80 Hz, Gain: 0 to 12 dB |
| Speaker Terminal Wire Gauge | 8 AWG |
| Strapable | Yes |
| Epicenter Link | Yes |
More specs
| |
What's Included
- EPIC750
- Wrench
- Screws
- ACR-E Remote Level Control and Cable
- The Epicenter Link (1m Harness)
- Manual
- Warranty
AudioControl
About the AudioControl EPIC750
From our tech experts at CEN
A monoblock subwoofer amplifier from AudioControl, rated at 750w RMS.
Who it suits
Anyone adding a subwoofer that needs controlled power rather than a compact powered unit. AudioControl built its name on signal processing, and that thinking runs through the amplifiers too.
Our tech experts advise
Matching matters more than headline watts, the gains want setting with a meter, and it needs a fused feed from the battery on the correct cable gauge. Installation is priced per vehicle, so get in touch with your make, model and year and we will confirm what it needs. See car audio installation.
Explore the full AudioControl range at CEN, with fast UK dispatch and expert advice from our Nottingham team. Shop all AudioControl
Recommended For You
Discover more top-rated gear, handpicked to go with what you're viewing
Looking for Installation?
At CEN we take pride in being able to share the quality of our work as well as being able to show what incredible products we have installed week on week.
More from AudioControl
More options from the same range, in stock and ready to go
Frequently Asked Questions
Q: Does the EPIC750 come with a bass knob?
A: Yes. The ACR-E remote level control and cable are included in the box, along with The Epicenter Link (1m harness), wrench, screws, manual and warranty.
Q: Can the EPIC750 be strapped (bridged)?
A: Yes. The EPIC750 is strappable, rated at 1 x 1500 W RMS at 2 ohms bridged (strapped).
Q: What is the Epicenter Link on the EPIC750?
A: It is a direct connection for power, ground and remote turn-on to The Epicenter bass restoration processor (sold separately), simplifying installation and keeping wiring tidy.
