Vibe Cven CVEN10SW-V7 10 Inch Sub SQ Component 4 Ohm Subwoofer 400w RMS

The Vibe CVEN10SW-V7 is a 10 inch, 4 ohm SQ component subwoofer rated at 400W RMS (800W peak), from Vibe's CVEN range. It is built for sound quality applications in sealed or bass reflex enclosures.

Key specifications

• Model: CVEN10SW-V7
• Size: 10 inch
• Power handling: 400W RMS / 800W peak
• Impedance: 4 ohm
• Sensitivity: 84dB
• Frequency response: 25Hz – 1.5kHz
• Voice coil: 2 inch, 4 layer
• Mounting depth: 148mm (5.8 inch)
• Enclosure volume: 0.75 – 1.5 cubic feet

CVEN10SW-V7 10 Inch 800W High-End SQ Component Subwoofer

The CVEN10SW-V7 is designed to reproduce the pitch and detail of music accurately, not just deliver volume. It is a high-performance subwoofer aimed at SQ competitors and critical listeners.

Features

• Extreme overhung voice coil with +/-16mm of linear stroke for low distortion at high drive levels.
• FEA optimised suspension for improved symmetry and lower distortion.
• Large motor structure with 2 inch voice coil for better control and power handling.
• Balanced drive motor for optimal drive force symmetry, reducing even order harmonic distortion.
• Rigid aluminium cone for linear piston motion at high levels and improved heat transfer under sustained power.
• Dual-spider design for higher mechanical durability and high-excursion stability.
• Die cast aluminium chassis with extensive venting to reduce air flow speed and audible distortion.
• Vented centre pole with dual flares to reduce noise at large cone excursions.
• Fibre glass voice coil former to reduce mechanical losses for better dynamic performance and low-level detail.
• Two built-in aluminium field-stabilising rings for reduced distortion at high levels.
• Low-loss suspension (high Qm) for better reproduction of detail and dynamics.
• Black plated motor parts for improved heat transfer to surrounding air.
• CONEX spider for durability under extreme conditions.
• Supplied with foam gasket attached for straightforward mounting and secure cabinet sealing.

The CVEN10SW-V7 is mechanically well balanced, offering controlled bass and very low compression through its excursion range. The CONEX spider and foam rubber surround are matched in compliance. It is suitable for both sealed and bass reflex enclosures.

Two internally fitted aluminium rings stabilise the magnetic field for lower distortion at high levels. The linear suspension uses a specially designed CONEX damper for long-term durability under extreme operating conditions. The rigid aluminium cone maintains linear piston motion at high levels and aids heat transfer during sustained high-power use.
