Kicker 46L7T124 L7T 12″ Shallow Dual 4 Ohm Subwoofer 600w

The Kicker 46L7T124 is a 12" square Solo-Baric L7T shallow-mount subwoofer with dual 4 ohm voice coils, rated at 600W RMS (1200W peak). It belongs to Kicker's L7T thin-profile subwoofer range, with a mounting depth of just 4-1/8" (10.5 cm) for under-seat and behind-seat installs.

This listing is the bare driver. The L7T 12" is also available pre-loaded in the Kicker 49L7TDF122 down-firing loaded enclosure.

Key specifications

• Size: 12" square
• Impedance: dual 4 ohm voice coils
• Power handling: 600W RMS, 1200W peak
• Sensitivity: 86.54 dB 1W/1m
• Frequency response: 25–100 Hz
• Mounting depth: 4-1/8" (10.5 cm)
• Square cutout: 11-1/16" (28.1 cm)
• Sealed box volume: 15.6–35.4 L
• Vented box volume: 49.6–63.7 L

Which L7T 12" version do I need?

This is the dual 4 ohm 46L7T124. Its coils wire in parallel for 2 ohm or in series for 8 ohm, making it a good match for amplifiers rated down to 2 ohm and for two-sub systems. If you want maximum output from a single sub on a 1 ohm stable amp, choose the dual 2 ohm L7T 12" (46L7T122).

Features

• Suits sealed or ported enclosures
• Square design delivers up to 20% more cone area than a round sub
• Shallow 4-1/8" mounting depth for under-seat or behind-seat fitment
• Dual voice coil design
• Ribbed Santoprene surround resists heat and degradation
• Bumped top plate for increased excursion and smoother performance
• SoloKon cone with 360-degree back bracing
• UniPlate solid pole piece and backplate for efficient heat dissipation
• Durable steel basket

The 46L7T124 is rated for 600W RMS and works with a sealed or ported enclosure. Kicker recommend pairing any L7T thin sub with a KX-Series mono amplifier for a compact, high-output install.
