The Kicker 46L7T104 is a 10" square, shallow-mount subwoofer from the Solo-Baric L7T range, with dual 4 ohm voice coils and 500W RMS power handling. Its 3-3/4" (9.5 cm) mounting depth makes it suitable for under-seat and behind-seat installations where a standard subwoofer won't fit.
This listing is the dual 4 ohm version. The L7T 10" is also available in a dual 2 ohm 46L7T102, and comes pre-loaded in the 46TL7T102 thin-profile enclosure.
Key specifications
- Size: 10" square
- Impedance: dual 4 ohm voice coils
- Power handling: 500W RMS, 1000W peak
- Sensitivity: 85.98 dB 1W/1m
- Frequency response: 25–100 Hz
- Mounting depth: 3-3/4" (9.5 cm)
- Square cutout: 9-5/16" (23.7 cm)
- Sealed box volume: 11.3–28.3 L
- Ported box volume: 35.4–49.6 L
L7T 10" thin-profile square subwoofer
The L7T's shallow mounting depth is its only concession to size. The cone area, power handling and build quality are full-spec. The square design gives up to 20% more cone area than a comparable round subwoofer, and the 3-3/4" depth fits under or behind most seats.
SoloKon technology combines an injection-moulded polypropylene cone with 360-degree back bracing as a single solid unit, cooling the motor and reducing distortion. Patented ribbed corners are built into the high-roll Santoprene surround for smooth movement under high SPL. The cone is stitched to the surround for added structural integrity.
Pair the 46L7T104 with a Kicker KX-Series mono amplifier for a compact, high-output combination suited to tight install spaces.
Features
- Compatible with sealed or ported enclosures
- Square design with up to 20% more cone area than a round sub
- 3-3/4" mounting depth — fits under or behind a seat
- Dual voice coil design
- Ribbed Santoprene surround resists heat and degradation
- Bumped top plate for increased excursion and smoother performance
- SoloKon cone with 360-degree back bracing
- UniPlate solid pole piece and backplate for heat dissipation
- Durable steel basket
Explore the full range in Kicker L7 Subwoofers.
Specification
| Style | Shallow |
|---|---|
| Impedance | (Ohms) Dual 4 |
| Voice Coils | Dual |
| RMS Power (W) | 500 |
| Peak Power (W) | 1000 |
| Sensitivity | (dB @ 1W/1m) 85.98 |
| Frequency Response | (Hz) 25-100 |
| Mounting Depth | 3 3/4" (9.5 cm) |
| Mounting Square Cutout | 9 5/16" (23.7 cm) |
| Min Sealed Box | 0.4 cu. ft. (11.3 L) |
| Max Sealed Box | 1.0 cu. ft. (28.3 L) |
| Min Vented Box | 1.25 cu. ft. (35.4 L) |
| Max Vented Box | 1.75 cu. ft. (49.6 L) |
What's Included
- Kicker 46L7T104 Subwoofer
Kicker
About the Kicker 46L7T104
From our tech experts at CEN
A 10 inch subwoofer from the Solo-Baric L7 line, whose square cone gives more radiating area than a round driver of the same nominal size, with a 4 ohm voice coil so it can be wired to suit your amplifier.
Who it suits
Drivers who want serious output and have the space and the amplifier to do it justice. The shallow depth also opens up locations a conventional sub could not physically go.
Our tech experts advise
A subwoofer is only as good as its enclosure and the amplifier behind it. Box volume, port tuning and how the voice coils are wired decide what you actually hear. We build enclosures to suit the vehicle and match amplification at our Beeston workshop. Installation is priced per vehicle, so get in touch with your make, model and year and we will confirm what it needs. See car audio installation.
Explore the full Kicker range at CEN, with fast UK dispatch and expert advice from our Nottingham team. Shop all Kicker
Recommended For You
Discover more top-rated gear, handpicked to go with what you're viewing
Have it Fitted By Our Team
Our team fits car audio, stereos, dash cams and vehicle security at our workshop in Beeston, Nottingham. Tell us your vehicle and we'll confirm the parts and a fitted price.
- 1
Tell us your vehicle
Make, model and year, and what you'd like fitted.
- 2
We confirm the parts
Fascia, wiring and interfaces checked for your car, with a fitted price.
- 3
Fitted at our workshop
Bring it to our Beeston workshop and we do the rest.
Unit 25 Technology Drive, Beeston, Nottingham NG9 1LA
More from Kicker L7 Subwoofers
More options from the same range, in stock and ready to go
Frequently Asked Questions
Q: How deep is the Kicker 46L7T104?
A: The 46L7T104 needs a mounting depth of 3-3/4" (9.5 cm), with a square cutout of 9-5/16" (23.7 cm).
Q: What size box does the 46L7T104 need?
A: Kicker recommends a sealed box of 11.3-28.3 L or a vented box of 35.4-49.6 L (port volume excluded).
Q: How do I wire the dual 4 ohm voice coils on the 46L7T104?
A: Wire the two 4 ohm coils in parallel for a 2 ohm load, or in series for an 8 ohm load. Use an amplifier that is stable at the final load.
