Helix Next V Two Bridgeable 2 Channel Amp with V-AMP Link Amplifier 800w RMS

The Helix Next V Two is a bridgeable 2-channel Class D car amplifier from the Helix Next V range, delivering 2 x 200W RMS at 4 ohms, 2 x 400W RMS at 2 ohms, or 800W RMS bridged at 4 ohms. It features V-AMP Link, a DirectDSP input and Auto Gain Ranging for use in speaker or subwoofer systems.

Key specifications

• Amplifier type: 2-channel, Class D, bridgeable
• Power (RMS, 4 ohms): 2 x 200W
• Power (RMS, 2 ohms): 2 x 400W
• Power (RMS, bridged 4 ohms): 1 x 800W
• Inputs: 2 x RCA (0.5–8V), 2 x V-AMP Link, remote in
• Frequency response: 10 Hz – 22,000 Hz
• Signal-to-noise ratio: 109 dB; THD+N: < 0.004%
• Operating voltage: 10.5–18V
• Dimensions: 44 x 220 x 180 mm (H x W x D)

Bridgeable 2-channel with V-AMP Link, Amplifier Control Panel and DirectDSP input

The Next V Two combines audiophile sound quality with high output power. Its wideband frequency response, low distortion and excellent signal-to-noise ratio make it well suited to demanding music systems, whether running stereo speakers or a subwoofer in bridged mono.

• 2-channel Class D amplifier combining sound quality with high efficiency
• Bridgeable output channels for flexible system configurations and maximum power
• ACP (Amplifier Control Panel) for intuitive configuration of gain, input mode and input reference
• Auto Gain Ranging (AGR): automatically detects input sensitivity and sets gain for optimal sound quality
• Manual gain adjustment from 0.5 to 8 volts in 0.5V steps
• V-AMP Link: dedicated input for connecting a Helix V Series amplifier for subwoofer or high-power speaker applications
• DirectDSP input: tuned for maximum signal quality when used with Helix DSP products such as the Helix Next V Eight DSP
• MSM (Mono/Stereo Mode): operates as a mono amplifier for subwoofers or stereo for speaker setups
• Stabilised Output Power (SOP) technology for consistent output regardless of input voltage
• Start-stop capable power supply with extended input voltage range up to 18V, suitable for modern EV platforms
• Auto Remote switch for amplifier activation without an external remote signal
• Compact design with low heat dissipation

Power meets audiophile performance

With a signal-to-noise ratio of > 109 dB, THD+N of < 0.004% and a high damping factor, the Next V Two meets demanding sonic requirements. Bridgeable outputs deliver maximum power where it is needed, making it a versatile choice for both speaker and subwoofer applications.

Stereo performance for versatile speaker applications

In full-range stereo, the Next V Two delivers 2 x 200W RMS at 4 ohms and 2 x 400W RMS at 2 ohms — sufficient for demanding midbass speakers or hybrid subwoofers. Wide frequency response and audiophile-grade characteristics ensure fine detail is reproduced accurately and without colouration.

Mono bridged operation for subwoofer applications

In bridged mode, the Next V Two delivers 800W RMS at 4 ohms, suitable for high-performance subwoofers including DVC2 subwoofers (2 x 2 ohms) from the Helix Impact Q series, or two series-wired SVC2 subwoofers (1 x 2 ohms) from the Helix Impact K series. Integrated mono mode allows a single input signal for full operation, making it ideal alongside a DSP providing a summed subwoofer output.
