Brax Matrix ML165 PRO 6.5 Inch High End Woofer 120w RMS Pair

The Brax Matrix ML165 PRO is a pair of handcrafted 165mm (6.5 inch) high-end woofers rated at 120W RMS, featuring a carbon fleece multilayer cone and copper-capped magnet system. Made in Germany, it is part of the Brax Matrix PRO range and succeeds the Matrix ML6 D.

This listing is for the ML165 PRO 6.5 inch woofer. The Brax Matrix PRO range is also available as the Brax Matrix ML80 PRO 3 inch midrange speaker.

Key specifications

• Size: 165mm / 6.5" woofer, sold as a pair
• Power handling: 120W RMS / 170W max
• Impedance: 4 ohms
• Frequency response: 40 Hz – 4,000 Hz
• Sensitivity: 88 dB @ 1W/1m (91 dB @ 2.83V/1m)
• Cone: carbon fleece multilayer
• Installation diameter: 143mm
• Installation depth: 64mm

Brax Matrix ML165 PRO: handcrafted 165mm / 6.5" high-end woofer

The Brax Matrix ML165 PRO is the next evolution of the Matrix ML6 D — long regarded as a benchmark for natural music reproduction. It combines refined engineering, advanced materials and precise construction to raise midbass performance for listeners who accept no compromise.

Features

• Ultra-lightweight carbon fleece multilayer cone — superior stiffness-to-weight ratio with reduced resonance for precise, dynamic sound
• Copper cap on the pole core — minimises voice coil inductance, linearises high-frequency impedance and enhances transparency
• Hemispherically shaped dust cap — optimises upper midrange response for seamless tonal transitions and detail resolution
• Aerodynamically shaped aluminium die-cast basket — allows ideal voice coil ventilation while minimising airflow noise
• High-strength Nomex spider — meta-aramid fabric construction for long-term shape stability under demanding conditions
• Specially shaped butyl rubber surround — enables maximum linear cone excursion with minimal distortion
• Ultra-precise machined magnet system — delivers symmetrical magnetic flux, impulse accuracy and powerful low-frequency performance
• Vented pole core and spider — improves airflow and reduces compression at high sound pressure levels
• Massive 24-carat gold-plated terminals — maximum conductivity and signal integrity
• Made in Germany — developed and manufactured for reference-level sound quality

Carbon fleece multilayer cone: light, rigid and resonance-free

The carbon fleece multilayer cone was developed in collaboration with specialist Dr. Kurt Müller. Its layered carbon structure combines extreme stiffness with minimal mass, reducing unwanted resonances. A reinforcement collar on the rear at the surround transition increases torsional stiffness and prevents deformation at high excursion levels. The straight cone geometry at the voice coil former optimises power transfer and ensures precise, controlled sound radiation.

Copper cap for maximum linearity

The copper cap on the pole core generates controlled eddy currents that damp magnetic field fluctuations, reduce voice coil inductance, linearise high-frequency impedance and lower distortion. The result is a smoother frequency response, higher efficiency and natural reproduction across the upper frequency range.

Precision and perfect control

The magnet system provides stable, symmetrical magnetic flux for strong impulse fidelity and dynamics across the full frequency range. The aluminium die-cast basket minimises airflow turbulence and maintains thermal stability with minimal compression at high output levels. The rubber surround enables linear cone excursion with minimal distortion, while the Nomex spider maintains consistent centring and long-term mechanical durability. 24-carat gold-plated terminals ensure maximum conductivity and signal integrity.

Elegant design — functional and aesthetic

The ML165 PRO's silk-matte cone surface, matt black powder-coated aluminium basket and golden accent ring around the dust cap give it a distinctive, refined appearance suited to seamless integration into any vehicle interior.

Made in Germany — reference-level sound culture

Like every speaker in the Brax Matrix series, the ML165 PRO is crafted in Germany, assigned an individual serial number registered in the Brax database, and delivered in a tailor-made wooden box. It represents uncompromising craftsmanship and audiophile precision at reference level.
