JL Audio MBT-RXv2 Bluetooth 5.0 Wireless Receiver for Amplifiers with RCA Outputs

£64.90 Popular
Black Friday
In stock
SKU: 91019MPN: MBT-RXv2
Part of the range · 15 productsPart of the JL Audio Accessories range · 15 products See the range →

The JL Audio MBT-RXv2 is a compact, water-resistant (IPX7) Bluetooth 5.0 audio receiver with Qualcomm aptX HD that adds wireless music streaming to any amplifier or source unit with line-level RCA inputs. It is part of JL Audio's MBT wireless receiver range.

This listing is the MBT-RXv2 receiver-only model. The MBT range is also available with an integrated controller in the JL Audio MBT-CRXv3.

Key specifications

  • Bluetooth: Version 5.0, A2DP, Qualcomm aptX HD
  • Outputs: One stereo pair, low-level RCA, 4V RMS
  • Frequency response: 20 Hz – 20 kHz (±1 dB)
  • S/N ratio: 100 dB
  • Connection range: Up to 11 m (35 ft)
  • Operating voltage: 10–16 VDC, 40 mA current draw
  • Remote turn-on output: +12V, 1 amp
  • Water resistance: IPX7

MBT-RXv2: water-resistant audio receiver with Bluetooth wireless technology

The MBT-RXv2 is designed to add high-quality streaming audio to virtually any sound system. It is a Bluetooth receiver only and does not have an auxiliary (AUX) audio input.

Equipped with Bluetooth 5.0 and the Qualcomm aptX HD codec, it delivers audio to any amplifier or source unit with line-level inputs via a pair of 4V RMS RCA preamp outputs.

The sealed, IPX7-rated chassis makes it well suited to challenging outdoor and marine installations, and its compact size means it fits into almost any location. Pairing is straightforward, with automatic reconnection on subsequent use. Playback, volume and media selection are all controlled from your streaming device at distances of up to 11 metres (35 ft).

The MBT-RXv2 also includes a +12V (1 amp) remote turn-on output for amplifier control.

Specification
Frequency Response20 Hz - 20 kHz (±1dB)
More specs
  • Bluetooth® Profile A2DP (High-Quality, Stereo Audio)
  • Bluetooth® Core Specification Version 5.0 with Qualcomm® aptX™-HD audio
  • Outputs One Stereo Pair, Low-Level RCA Plugs
  • Output Voltage 4V RMS
  • S/N Ratio 100 dB (20 Hz - 20 kHz)
  • Input Operating Voltage 10 - 16 VDC
  • Current Draw 40 mA
  • Fuse Rating 2 A Mini ATC
  • Connection Range* Up to 35' / 11 m
  • *Maximum range is achieved in line-of-sight installations. While the receiver can be mounted in a hidden location, actual range will vary based on installation specifics.
What's Included
  • JL Audio MBT-RXv2
Product information

JL Audio

About the JL Audio MBT-RXv2

From our tech experts at CEN

A wireless Bluetooth receiver that feeds a JL Audio amplifier directly.

Who it suits

Anyone who wants to stream to an amplified system without routing audio through a weak factory head unit, and marine builds where there may be no head unit at all.

Our tech experts advise

Where it sits in the signal chain decides what you hear. Confirm compatibility with your amplifier before ordering — get in touch. See car audio installation.

Explore the full JL Audio range at CEN, with fast UK dispatch and expert advice from our Nottingham team. Shop all JL Audio

Recommended For You

Discover more top-rated gear, handpicked to go with what you're viewing

Frequently Asked Questions

Q: Does the JL Audio MBT-RXv2 have an AUX input?

A: No. The MBT-RXv2 is a Bluetooth receiver with one stereo pair of RCA outputs (4V RMS). It feeds an amplifier or source unit that has line-level inputs.

Q: Is the MBT-RXv2 waterproof?

A: It has a sealed, IPX7-rated water-resistant chassis, which makes it well suited to outdoor, marine and powersports installs.

Q: Can the MBT-RXv2 turn my amplifier on?

A: Yes. It has a +12V remote turn-on output rated at 1 amp for switching an amplifier on and off.

Q: What is the Bluetooth range of the MBT-RXv2?

A: Up to 11 metres (35 ft). Maximum range is achieved in line-of-sight installations, and actual range varies with where the receiver is mounted.
