JL Audio 10W1v3-2 10" 25cm W1 Series Car Sub Subwoofer Driver 2ohm 300w RMS

£249.00 Out of stock
Black Friday
Out of Stock
SKU: 90920MPN: 10W1V3-2
Part of the range · 60 productsPart of the JL Audio Subwoofers range · 60 products See the range →

The JL Audio 10W1v3-2 is a 10" (250mm) W1 Series car subwoofer driver rated at 300W RMS with a 2-ohm impedance. It features a shallow 117mm mounting depth and is optimised for compact sealed enclosures.

Key specifications

  • Size: 10 inch (250mm)
  • Power handling: 300W RMS (75–300W recommended)
  • Impedance: 2 ohms
  • Mounting depth: 117mm (4.6 inch)
  • Sealed enclosure volume: 0.55 cu ft (15.57 litres)
  • Linear excursion: 11mm one-way
  • Pole vent: none — motor structure can sit directly against an enclosure wall

W1v3 10-inch Subwoofer (300W, 2Ω)

The 10W1v3-2 is an ideal choice where space is tight and amplifier power is moderate. Its shallow 4.6 in. (117mm) mounting depth and compact motor structure allow it to fit in many locations where a standard 10-inch driver will not. With no pole vent, the rear of the motor can be placed directly against an enclosure boundary. Strong excursion capability and linearity deliver extended sub-bass reproduction. Several JL Audio proprietary technologies are used to enhance performance and reliability.

This driver is best matched with amplifier power in the 75W–300W range and is optimised to operate in a compact 0.55 cu. ft. (15.57 l) sealed enclosure.

Specification
Mounting Depth(E) 4.6 in / 117 mm
More specs
  • Continuous Power Handling (RMS) 300 W
  • Recommended Amplifier Power (RMS) 75 - 300 W
  • Nominal Impedance (Znom) 2 Ω
  • Nominal Diameter 10.0 in / 250 mm
  • Overall Diameter (A) 10.5 in / 267 mm
  • Mounting Hole Diameter (B) 9.0625 in / 230 mm
  • Bolt Hole Circle Diameter (C) 9.7 in / 246 mm
  • Motor Outer Diameter (D) 4.92 in / 125 mm
  • Driver Displacement 0.037 cu ft / 1.05 L
  • Net Weight 9.9 lb / 4.5 kg
  • Free Air Resonance (Fs) 25.23 Hz
  • Electrical “Q” (Qes) 0.463
  • Mechanical “Q” (Qms) 7.246
  • Total Speaker “Q” (Qts) 0.436
  • Equivalent Compliance (Vas) 1.559 cu ft / 44.15 L
  • One-Way Linear Excursion (Xmax)* 0.45 in / 11 mm
  • Reference Efficiency (no) 0.16%
  • Efficiency (1 W / 1 m)** 83.9 dB SPL
  • Effective Piston Area (Sd) 53.584 sq in / 0.0346 sq m
  • DC Resistance (Re) 2.233 Ω
What's Included
  • 10W1v3-2
  • Black plastic trim ring
  • Owner's manual
Product information

JL Audio

About the JL Audio 10W1V3-2

From our tech experts at CEN

A JL Audio 10 inch W1 Series subwoofer driver, 2 ohm, handling 300w RMS.

Who it suits

Drivers building a system around a properly specified enclosure rather than a box off the shelf. W1 sits a step above W0, with more control for the money.

Our tech experts advise

This is a driver, not a finished system: enclosure volume and tuning decide most of what you hear, and JL publish specifications worth building to, and the 2 ohm coil decides how it should be wired to your amplifier. We build enclosures to suit both driver and vehicle at our Beeston workshop. Installation is priced per vehicle, so get in touch with your make, model and year and we will confirm what it needs. See car audio installation.

Explore the full JL Audio range at CEN, with fast UK dispatch and expert advice from our Nottingham team. Shop all JL Audio

Recommended For You

Discover more top-rated gear, handpicked to go with what you're viewing

Car audio installation by CEN in Nottingham

Have it Fitted By Our Team

Our team fits car audio, stereos, dash cams and vehicle security at our workshop in Beeston, Nottingham. Tell us your vehicle and we'll confirm the parts and a fitted price.

  1. 1

    Tell us your vehicle

    Make, model and year, and what you'd like fitted.

  2. 2

    We confirm the parts

    Fascia, wiring and interfaces checked for your car, with a fitted price.

  3. 3

    Fitted at our workshop

    Bring it to our Beeston workshop and we do the rest.

Unit 25 Technology Drive, Beeston, Nottingham NG9 1LA

Car audio installation by CEN in NottinghamCar audio installation by CEN in NottinghamCar audio installation by CEN in NottinghamCar audio installation by CEN in Nottingham

Frequently Asked Questions

Q: Do I need an amplifier for this subwoofer?

A: Yes, unless it is an active (powered) subwoofer with a built-in amplifier. Passive subwoofers need an external amplifier matched to the RMS power and impedance shown in the Specification tab.

Q: What size enclosure does this subwoofer need?

A: The recommended enclosure volume is listed in the Specification tab where the manufacturer provides it. As a rule, sealed enclosures give tighter, more accurate bass while ported enclosures deliver more output. Contact CEN if you would like a recommendation for your build.

Q: What does RMS power mean?

A: RMS is the continuous power a subwoofer can handle, and it is the number that matters when matching an amplifier. Peak or max figures describe short bursts only. Match your amplifier output to the RMS rating in the Specification tab.

Q: Sealed or ported enclosure - which should I choose?

A: Sealed boxes are compact and produce tight, controlled bass suited to sound quality builds. Ported boxes are larger and produce more output at low frequencies, suited to those who want maximum impact. Either works well when built to the recommended volume.

Q: Can CEN build or supply an enclosure and fit everything?

A: Yes. CEN supplies enclosures and offers professional installation from our Nottingham premises, including amplifier wiring. Contact us to discuss your build.

Q: What enclosure does the JL Audio 10W1v3-2 need?

A: It is optimised for a compact 0.55 cu ft (15.57 litre) sealed enclosure.

Q: How deep is the 10W1v3-2?

A: The mounting depth is 117 mm (4.6 inch). It has no pole vent, so the rear of the motor can be placed directly against an enclosure wall.

Q: What's in the box with the 10W1v3-2?

A: The 10W1v3-2 driver, a black plastic trim ring and an owner's manual.
