Helix M One X Mono Subwoofer Amp 1 Channel Class D Amplifier 1030w RMS 1 Ohm
HELIX M ONE X 1 Channel Class D Amplifier HELIX M ONE X
Small, efficient and uncompromisingly stable - the M ONE X is a highly compact monoblock for subwoofer applications. Designed from latest Class D technology this tiny amp can easily control speakers with 1 Ohm impedance. Its current capability makes the M ONE X a perfect partner for 2 x 2 Ohms subwoofers, where both voice coils are connected in parallel. And for even more output power, two M ONE X amplifiers can be combined to one single powerhouse – thanks to the TwinPower Link.
In addition a comprehensive and stunningly practical feature set leaves nothing to be desired. Last but not least installation will be a no-brainer due to the minimal dimensions.
Features
- Small footprint Class D amplifier with up to 1,180 Watts RMS output power @ 1 Ohm for easiest combination with all 2 x 2 Ohms subwoofers connected in parallel
- Start-Stop capability down to 6V supply voltage
- Smart highlevel input with ADEP circuit and Auto Turn-On function
- Integrated, active crossover with lowpass, bass boost, subsonicand phase control
- TwinPower Link for connecting two amplifiers in bridged mode
- Bass remote control for volume adjustment
- Low heat dissipation thanks to extraordinary efficiency
Smart highlevel input
The latest generation of OE car radios incorporates sophisticated possibilities of diagnosing the connected speakers. If a common amplifier will be hooked up failure messages and loss of specific features (e.g. fader function) quite often appear - but not with the M ONE.
The new ADEP circuit (Advanced Diagnostics Error Protection) avoids all these problems without loading the speaker outputs of the OE radio during high volumes unnecessarily.
Start-Stop capability
The switched power supply of the HELIX M ONE assures operation even if the battery’s voltage drops down to 6 Volts during engine crank.
Specification
Part Number: M ONE X
- Power RMS ≤ 1% THD+N Normal operation
- (One amplifier) TwinPower Link
- (Two amplifiers)
- - @ 4 Ohms 1 x 400 Watts 1 x 1,400 Watts
- - @ 2 Ohms 1 x 700 Watts 1 x 2,060 Watts
- - @ 1 Ohm 1 x 1,030 Watts -
- - bridged @ 4 Ohms - -
- - bridged @ 2 Ohms - -
- Max. output power per channel*: Up to 1,180 Watts RMS @ 1 Ohm
- Amplifier technology Class D
- Inputs 2 x RCA / Cinch
- 2 x Highlevel speaker input
- 1 x Remote In
- 1 x Remote control input
- Input sensitivity RCA / Cinch 0.5 - 6 Volts
- Highlevel 1.1 - 13 Volts
- Input impedance RCA / Cinch 20 kOhms
- Input impedance highlevel 9 - 33 Ohms
- Outputs 1 x Speaker output
- Output voltage RCA / Cinch -
- Signal converter for digital input -
- Frequency response 10 Hz - 250 Hz
- Bass boost 0 - 12 dB / 30 - 80 Hz
- Highpass -
- Lowpass 50 Hz - 250 Hz adjustable
- Bandpass 10 Hz - 250 Hz adjustable
- Subsonic 10 Hz - 50 Hz adjustable
- Phase 0 - 180° adjustable
- Slope high- / lowpass -
- Slope subsonic / lowpass 12 / 24 dB/Oct.
- Signal-to-noise ratio digital input -
- Signal-to-noise ratio analog input 95 dB (A-weighted)
- Distortion (THD) 0.20 %
- Damping factor 150
- Operating voltage 10.5 - 16 Volts (max. 5 sec. down to 6 Volts)
- Idle current 800 mA
- Fuse 3 x 40 A Maxi-fuse (APX)
- Additional features Active, adjustable crossover, bass boost, phase shift, Start-Stop capability, highlevel input with automatic turn on function and Advanced Diagnostics Error Protection (ADEP), bass volume cable remote control
- Dimensions (H x W x D) 50 x 320 x 154 mm /
- 2.00 x 12.60 x 6.06”
* In typical applications as subwoofer amplifier
What's Included
2 Year Warranty
- Amplifier HELIX M ONE X
- Cable remote control
- Mounting material
- Instruction manual
