AudioControl EPICX Series 10 Inch 2 Ohm Subwoofer 500w
Couldn't Load Pickup availability
The AudioControl EPICX Series EPIC X10D2 is a 10-inch car subwoofer with dual 2 ohm voice coils, rated at 500W RMS / 750W max, from AudioControl's EPICX Series range.
This listing is for the EPIC X10D2 (dual 2 ohm). The EPICX Series 10-inch subwoofer is also available as a dual 4 ohm version.
Key specifications
- Size: 10 in / 250 mm
- Power handling: 500W RMS / 750W max
- Impedance: dual 2 ohm voice coils (DVC)
- Voice coil: 2.38 in
- Resonance frequency (Fs): 39.8 Hz
- Efficiency: 84.8 dB
- Cut-out diameter: 9.25 in / 235 mm
- Mounting depth: 5.3 in / 135.8 mm
- Recommended enclosure: 0.625 ft³ sealed or 1.25 ft³ ported (tuned to 35 Hz)
About the EPICX Series
The EPICX Series combines strong output with refined audio quality. These subwoofers deliver tight, accurate low-end response that stays clean at high volume — built for street systems and competition use alike.
Non-pressed paper cones, heavy-duty motor structures and high-quality components are used throughout, optimised for output, efficiency and durability under heavy demand.
Features
- Composite foam surround: smooth, controlled bass.
- High-precision motor assembly: maximises efficiency and output, converting amplifier power into impactful bass.
- Rigid steel basket: low resonance for tighter bass and clearer sound.
- High-temperature, lightweight voice coil: fast, dynamic bass response with reliability under high power.
- One-piece dust cap design: enhances cone rigidity for consistent, low-distortion bass.
- Non-pressed paper cone: natural depth and rich low-end character.
- Large-gauge, quick-release black nickel terminals: high conductivity with a secure, vibration-proof connection.
- Engineered to integrate with AudioControl's EPICENTER bass restoration processor for deeper low frequencies.
Explore the full range in AudioControl EPICX Series.
Specification
| Speaker Size | 10 in / 250 mm |
|---|---|
| Power | 500W RMS / 750W Max |
| Impedance | 2 ohms |
| Voice Coil | 2.38 in |
| Resonance Frequency | 39.8 Hz |
| Efficiency | 84.8 dB |
| Magnet | Dimensions 6.14 x 2.95 x 0.98 in / 156 x 75 x 25 mm |
| Overall Diameter | 10.5 in / 269 mm |
| Cut Out Diameter | 9.25 in / 235 mm |
| Mounting Depth | 5.3 in / 135.8 mm |
| Mounting Height | 1 in / 24 mm |
| Motor Diameter (w/ Cover) | 6.4 in / 162 mm |
| External Dimensions | 20.5″ W × 13.5″ H × 11.5″ D |
| Net Internal Volume | 1.25 ft3 |
| Exterior Volume | 1.84 ft3 |
| Material Thickness | 0.75 in |
| Port Area | 15 sq in |
| Port Inlet | 1.25″ W × 12″H |
| Port Length | 23 in |
| Tuning Frequency | 35 Hz |
| External Dimensions | 14″ W × 12.75″ H × 11″ D |
| Internal Volume | 0.625 ft3 |
| Material Thickness | 0.75 in |
What's Included
- EPIC X10D2
- Manual
AudioControl
About the AudioControl EPIC X10D2
From our tech experts at CEN
An AudioControl 10 inch subwoofer, 2 ohm, handling 500w RMS.
Who it suits
Drivers building a system where the bass does real work rather than filling in behind the speakers.
Our tech experts advise
A subwoofer is only as good as its enclosure and the amplifier behind it: box volume and tuning decide what you actually hear, and impedance decides how it should be wired. We build enclosures to suit both driver and vehicle at our Beeston workshop. Installation is priced per vehicle, so get in touch with your make, model and year and we will confirm what it needs. See car audio installation.
Explore the full AudioControl range at CEN, with fast UK dispatch and expert advice from our Nottingham team. Shop all AudioControl
Recommended For You
Discover more top-rated gear, handpicked to go with what you're viewing
Looking for Installation?
At CEN we take pride in being able to share the quality of our work as well as being able to show what incredible products we have installed week on week.
More from AudioControl
More options from the same range, in stock and ready to go
Frequently Asked Questions
Q: Do I need an amplifier for this subwoofer?
A: Yes, unless it is an active (powered) subwoofer with a built-in amplifier. Passive subwoofers need an external amplifier matched to the RMS power and impedance shown in the Specification tab.
Q: What size enclosure does this subwoofer need?
A: The recommended enclosure volume is listed in the Specification tab where the manufacturer provides it. As a rule, sealed enclosures give tighter, more accurate bass while ported enclosures deliver more output. Contact CEN if you would like a recommendation for your build.
Q: What does RMS power mean?
A: RMS is the continuous power a subwoofer can handle, and it is the number that matters when matching an amplifier. Peak or max figures describe short bursts only. Match your amplifier output to the RMS rating in the Specification tab.
Q: Sealed or ported enclosure - which should I choose?
A: Sealed boxes are compact and produce tight, controlled bass suited to sound quality builds. Ported boxes are larger and produce more output at low frequencies, suited to those who want maximum impact. Either works well when built to the recommended volume.
Q: Can CEN build or supply an enclosure and fit everything?
A: Yes. CEN supplies enclosures and offers professional installation from our Nottingham premises, including amplifier wiring. Contact us to discuss your build.
Q: Is the EPIC X10D2 a 2 ohm or 4 ohm subwoofer?
A: The EPIC X10D2 has dual 2 ohm voice coils (DVC). AudioControl also makes a dual 4 ohm version of the same 10 inch EPICX subwoofer.
Q: What box does the EPICX 10 inch subwoofer need?
A: AudioControl recommends a sealed enclosure of 0.625 ft3 internal volume, or a ported enclosure of 1.25 ft3 net internal volume tuned to 35 Hz. Full enclosure dimensions are listed in the Specification tab.
Q: What is the mounting depth of the EPIC X10D2?
A: The mounting depth is 5.3 in / 135.8 mm and the cut-out diameter is 9.25 in / 235 mm.
