The AudioControl Altitude A800.1 is a monoblock subwoofer amplifier rated at 800 W RMS at 1.33 ohms, part of AudioControl's Altitude Amplifier Series.
Key specifications
- Channels: 1 (monoblock)
- Power (RMS at 14.4V): 400 W at 4 ohms, 600 W at 2 ohms, 800 W at 1.33 ohms
- Inputs: 2, high/low input modes (low 6V max, high 20V max)
- Crossover: Linkwitz-Riley low pass, 60 Hz to 120 Hz
- Bass processing: ParaBASS, variable subsonic filter
- S/N ratio: 110.2 dBA (ref rated power)
- Spike Mode, Valet Mode, start-stop compliant, EV compliant up to 17V
- Remote level control: ACR-1 (optional)
- Dimensions: 10.9" W x 6.7" D x 2.1" H, 6.05 lbs
AudioControl Altitude Amplifier Series
The Altitude Series is built with a minimalist aesthetic and effective heat dissipation, allowing the A800.1 to run cool at maximum output for extended periods.
Features
- High/low input modes
- GTO Signal Sense
- Linkwitz-Riley crossovers
- Start-stop compliant
- ParaBASS low frequency contouring
- Valet Mode option
- Optional remote level control (ACR-1)
- EV compliant up to 17V
- Spike Mode enabled
Valet Mode limits maximum volume to 25% when activated, protecting your system from unintended damage. The A800.1 is also compatible with start-stop systems and electric vehicles up to 17V.
Spike Mode lets you connect three 4 ohm subwoofers at 1.33 ohms, unlocking the full 800 W RMS from the amplifier. ParaBASS control knobs allow precise low-frequency tuning to suit your preference.
If your vehicle uses a factory head unit, AudioControl's LC2i 2 Channel Line Out Converter or LC7i 6 Channel Line Out Converter can be used to feed a clean RCA signal into the A800.1.
Explore the full range in AudioControl Altitude Marine.
Specification
| Channels | 1 |
|---|---|
| Inputs | 2 |
| Low | 6V max |
| High | 20V max |
| S/N Ratio (ref | rated power): 110.2 dBA |
| Valet Mode | Y |
| THD+N | <0.14% |
| Subsonic Filter | Variable |
| Linkwitz-Riley X-Over Freq. Range | 60 Hz to 120 Hz |
| Bass Processing | ParaBASS® |
| Remote Level Control | ACR-1 (optional) |
| Dimensions | 10.9” W x 6.7” D x 2.1” H |
| Weight | 6.05 lbs |
More specs
| |
What's Included
- A800.1 Amplifier
- Manual
- Warranty
AudioControl
About the AudioControl A800.1
From our tech experts at CEN
The AudioControl Altitude A800.1 is a monoblock subwoofer amplifier delivering 800W RMS at 1.33 ohms (400W at 4 ohms, 600W at 2 ohms). Part of AudioControl's Altitude Series, it includes a Linkwitz-Riley low-pass crossover (60–120 Hz), ParaBASS bass contouring, a variable subsonic filter, and is start-stop and EV compliant up to 17V.
Who it suits
The A800.1 suits anyone upgrading to a dedicated subwoofer amplifier in a car or EV. Spike Mode allows three 4-ohm subwoofers to run at 1.33 ohms, making it well suited to multi-sub builds. For more power, the AudioControl Altitude A1500.1 offers 1500W.
Our tech experts advise
The A800.1 measures 10.9" wide, 6.7" deep and 2.1" high, so check your boot or under-seat space before buying. It accepts both high and low-level inputs, so a factory or aftermarket head unit will work. If your car has no RCA outputs, you will need a line output converter before connecting. Installation is priced per vehicle; see our car audio installation page for details.
Explore the full AudioControl range at CEN, with fast UK dispatch and expert advice from our Nottingham team. Shop all AudioControl
Recommended For You
Discover more top-rated gear, handpicked to go with what you're viewing
Have it Fitted By Our Team
Our team fits car audio, stereos, dash cams and vehicle security at our workshop in Beeston, Nottingham. Tell us your vehicle and we'll confirm the parts and a fitted price.
- 1
Tell us your vehicle
Make, model and year, and what you'd like fitted.
- 2
We confirm the parts
Fascia, wiring and interfaces checked for your car, with a fitted price.
- 3
Fitted at our workshop
Bring it to our Beeston workshop and we do the rest.
Unit 25 Technology Drive, Beeston, Nottingham NG9 1LA
More from AudioControl Altitude Marine
More options from the same range, in stock and ready to go
Frequently Asked Questions
Q: How does the A800.1 reach 800 W?
A: The full 800 W RMS is delivered at 1.33 ohms using Spike Mode, which lets you connect three 4 ohm subwoofers. At 2 ohms it delivers 600 W and at 4 ohms 400 W (at 14.4V).
Q: Does the A800.1 have a subsonic filter?
A: Yes. It has a variable subsonic filter plus a Linkwitz-Riley low pass crossover adjustable from 60 Hz to 120 Hz.
Q: Does the A800.1 come with a bass remote?
A: The ACR-1 remote level control is optional and sold separately. The box contains the amplifier, manual and warranty.
