Wavtech 12 Inch Professional Series Shallow Subwoofer ThinPro12 Sub 2 Ohm

thinPRO12 2 Ohm

12” Professional Series Shallow Subwoofer

The thinPRO12 has a mounting depth of just 3”, so it is really thin, but it does not perform like a shallow subwoofer.  Our Patent Pending design allows for some big performance advantages.  The dual mirrored NBR spiders and axial force transfer assembly acheive over 2-inches of peak to peak excursion.  Some popular models that are 10” deep don’t have this much excursion.  This is unheard of in a shallow subwoofer.

• 750 Watts RMS Power Handling
• 3” Mounting Depth
• 5” Voice Coil
• 4-Layer Winding on Vented Polymide Composite Former
• Protective Grille (TP12G Sold Separately)
• Honeycomb Nomex® and Glass Fiber Cone
• FEA Optimized Dual-Gap Motor Structure
• Double-Roll NBR Surround
• Mirrored Internal NBR Spiders
• 8AWG Push Terminals
• Vented Cast Aluminum Frame
• Dimensions: 11 1/8in (282mm) Standard 12” cutout

This is a shallow woofer, but it is big on performance.  The 5” voice coil, available in 2 or 4 ohm, handles an impressive 750W RMS power, unheard of in a shallow subwoofer.  The FEA optimized dual gap motor structure features a massive motor with double stacked strontium magnets.  This maximizes flux density and control for an impressive 20mm of linear xmax.  The cone is a honeycomb design, made of composite Nomex® and glass fiber.  This makes it extremely strong and lightweight.

The point of a shallow subwoofer is to fit places others won’t.   If it doesn’t work in a small box, what’s the point.  The thinPRO12 excels in both small sealed and ported enclosures.  In sealed applications, box sizes range from 0.4-1.0cu ft, with the optimum being 0.6cu ft.  Ported options range from 0.8-1.5cu ft, with 1.0cu ft being the ideal choice.
