Kicker 49WXA36001 1 Channel Class D Amplifier 3600w RMS
Couldn't Load Pickup availability
Warhorse 3600W Monoblock Class D Subwoofer Amplifier
49WXA36001
Every aspect of the Warhorse was tortured mercilessly in our labs to ensure extreme performance and reliability. It was engineered completely in-house by KICKER Research and Development for ultra-high SPL applications.
Fortified to Go Hard
From the board layout to the rails, to the Tiffany-style RCA connectors, everything about these amps will make a bass head smile from ear to ear. This full-bridge, one-Ohm stable amplifier features dual 1/0 power and ground connections, 4 AWG speaker terminals, dual 8 AWG remote terminals, and quad microprocessor-controlled fans for fast but quiet cooling when you need it.
Engage Competition Mode!
Engage Competition mode to set the input sensitivity to 4 volts, locking the gain potentiometer out for easy gain-matching across multiple amps, amongst other slick features.
Real-Time Status Tools
Warhorse Amps come with a heavy-duty, magnetic-mount diagnostic tool, displaying battery voltage, thermal protection status, power-supply protection, and speaker current overload, all in real time! A premium remote bass-level control, also with magnetic mount, is included with the mono amp as well.
Compatible!
It’s equipped with the KICKER FIT+™ (Fail-safe Integration Technology) differential inputs and a 125mV-40V RCA input range, so the amps are fully compatible with most all factory or aftermarket source units. It’s also start/stop compliant.
Features
- Features extreme reliability under intense bass power and overall use
- Engineered completely in-house by KICKER R&D
- Full-bridge Class-D design
- Quad micro-controller-regulated cooling fans
- Capable of daisy-chaining remote power across multiple amps
- Competition mode switch to avoid potentiometer creep, fix crossover setting, and gain-match multiple amps
- Includes premium remote bass-level control with a magnetic mount – 19.75 feet (6m) RJ45 cable
- Includes a heavy-duty, magnetic-mount diagnostic tool for monitoring voltage measurements and amp protection status – 19.75 feet (6m) RJ45 cable
- Fully compatible with most factory or aftermarket source units (with FIT+™ differential inputs)
Explore the full range in 1 Channel Amplifier.
Specification
| Dynamic Power (watts) | 5000 |
|---|---|
| Frequency Response | (Hz) 10-200 |
| Signal-to-Noise Ratio (dB; ref | 1W output): >70 |
| Input Sensitivity | low level 125mV-5V / high level 1V-40V |
| Selectable Electronic Crossover | Variable Low-pass 50-200Hz, 24dB/octave |
| Subsonic Filter | Defeatable @ 15Hz, 24dB/octave |
| Height | 6.5 |
| Width | 23.2 |
| Length | 39.1 |
More specs
| |
What's Included
- Kicker 49WXA36001
