Audison Voce AV 5.1K Amplifier Class A, AB & D Mono & Multi 5 Channel Amp 1650w
Pickup Currently Unavailable at CEN
VOCE AV 5.1k
Amplifier | 1650 W | 2 x 75 W @ 4ohm + 2 x 250 W @ 2ohm + 1 x 1000 W @ 2ohm | AB-class
VOCE
The precious synergy between Voce amplifiers and Full DA HD technology takes the in-car listening experience to a new level of excellence; the synthesis of a unique know-how employed in mobile audio reproduction.
- Hybrid design made up of two 75 W A Class channels, two 250 W AB Class channels, and one 1000 W D Class channel
- Hi-Res audio certification thanks to 4 ÷ 60k Hz bandwidth
AV 5.1k, 1650 W (RMS) max, five channels: with its hybrid design, it is the specialist amplifier for front + rear + subwoofer or multi-amplified front + subwoofer systems. Its high-quality AB Class output stage provides two channels with 250 W (RMS), combined with another pair of A class pure audio channels rated at 75 W (RMS), perfect for active two-way front speaker systems. The D Class mono section provides 1000 W (RMS) for powerful subwoofer output. AV 5.1k also allows you to replace the analog input board with the digital one (AV bit IN).
Specification
Part Number: AV 5.1k
- Channels 5
- Class AB-Class
- Hi Level Input Yes
- Low Level Input Yes
- Digital Input No
- Power supply voltage / fuse 11 ÷ 15 VDC
- Idling current 3 A
- Idling current when off 0.02 mA
- Consumption @ 14.4 VDC, 2Ω, Max Musical Power 110 A
- Remote OUT 12 VDC - 50mA
- Remote IN 7 ÷ 15 VDC - 1mA
- ART - Automatic Remote Turn on/off from OUTPUT BTL speakers (Selectable) Selectable
- Distortion - THD @ 100 Hz, 4Ω, 70% Rated Power A, B Ch: 0.05 % | C (sub) Ch: 0.3 %
- Bandwidth A (-3 dB) A, B Ch: 5 ÷ 20k Hz
- -3 dB) C (sub) Ch: 7 ÷ 350 Hz
- S/N ratio A (A weighted @ 1V): A, B Ch: 100 dB
- (A weighted @ 1V): C (sub) Ch: 87 dB
- Damping factor A (1k Hz @ 4Ω) A, B Ch: 100
- (100 Hz @ 4Ω) C (sub) Ch: 80
- Input sensitivity Pre-In 0.3 ÷ 5 V RMS
- Pre In Impedance 15k Ω
- Input sensitivity Speaker-In 1.4 ÷ 24 V RMS
- Input impedance Speaker-In 5k Ω
- Total Power RMS 1650 W
- Minimum load impedance 4Ω / 2Ω / 2Ω
- Output Power (RMS) @12.0 ÷ 14.4 VDC, 1% THD • 5 Ch: 75 W x 2 (4Ω) + 140 W x 2 (4Ω) + 600 W x 1 (4Ω)
- • 5 Ch: 75 W x 2 (4Ω) + 140 W x 2 (4Ω) + 1000 W x 1 (2Ω)
- • 5 Ch: 75 W x 2 (4Ω) + 250 W x 2 (2Ω) + 1000 W x 1 (2Ω)
- Adjustable Crossover Yes
- Input Type Pre IN / Speakers IN
- Filters Outputs Pre OUT Full Range
- Filter Pass A Ch Filters (Full / Hi-Pass): 50 ÷ 5k Hz (2 range) @ 12 dB/Oct.
- Filter Pass B Ch Filters (Full / Hi-Pass / Band-Pass): 50 ÷ 1k Hz (Hi) / 250 ÷ 5k (Lo) @ 12 dB/Oct.
- Filter Pass C Ch Filters (Full / Lo-Pass): 50 ÷ 150 Hz @ 24 dB/Oct.
- Remote Sub Volume -50 ÷ 6) dB
- Fuse 100 A
- Weight 7.2 kg
- Dimension 470 mm 399 mm 220 mm 198 mm 58 mm
What's Included
2 Year Warranty
- AV 5.1k amplifier
